RS Certified Inflatable Dock Fenders

Certification
China QINGDAO SHUNHANG MARINE SUPPLIERS CO., LTD. certification
I'm Online Chat Now

RS Certified Inflatable Dock Fenders

RS Certified Inflatable Dock Fenders
RS Certified Inflatable Dock Fenders RS Certified Inflatable Dock Fenders

Large Image :  RS Certified Inflatable Dock Fenders

Product Details:
Place of Origin: China
Brand Name: Shunhang
Certification: RS, CCS, ISO9001
Model Number: SH-MF2
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Price: USD 550 to 2600/PC
Packaging Details: Pallet package
Delivery Time: 5 to 20 workdays
Payment Terms: Western Union, , T/T, L/C
Supply Ability: 220pcs per month

RS Certified Inflatable Dock Fenders

Description
Product Name: RS Certified Good Air Tightness Inflatable Marine Rubber Fender Initial Internal Pressure: 50kpa, 80kpa
Tire: Truck Tires, Aircraft Tires Chain: HDG, Stainless
Shackle: HDG, S Warranty: 2 Years
Color: Black
High Light:

RS Certified inflatable dock fenders

,

50kpa Air Tightness inflatable dock fenders

,

50kpa marine dock fender

Ship to Ship Marine Rubber Fender Net Type Initial Internal Pressure 50kPa





Product Introduction



Marine Fenders is widely used in seaports. Large seagoing vessels use generally no fenders themselves for the mooring in the port. The exception is, for instance, when a bunker boat comes alongside, or when tankers are berthing at sea alongside each other to take over loads. In these situations, pneumatic marine fenders are often used.



When mooring under rough weather conditions, a ship is subjected to wave action, especially to swell, causing the ship to be moved up and down, back and forth and left to right at the quay. Pneumatic marine fenders allow gentle initial contact with a gradual increase of reaction force and large allowable deflection, meaning ships and mooring facilities are protected even under rough weather conditions. In light of these advantages, quite a few deep-water ports and large open-sea loading facilities employ pneumatic marine fenders.





Features of Marine Fender


High energy absorption with a low reaction force
Adjust performance by varying internal pressure
Chains and tire net protection for heavy duty use
Standard galvanized chains, shackles and swivel joints
Suitable for areas with tidal difference
Low maintenance
Low transportation costs
Manufactured in accordance with the ISO17357:2014





Fender types



1.Net-type fenders: fenders which are covered by a tire chain net, each end shall be linked together with one to two ring(s).

2.Sling-type fender: fenders which are designed to be used without a protection net.





Initial internal pressure



1.Pneumatic fender 50 (initial internal pressure 50 KPa)

2.Pneumatic fender 80 (initial internal pressure 80 KPa)





Specificaton of Marine Fender



Size Initial Internal Pressure 50kPa Initial Internal Pressure 50kPa

Diameter/

Meter

Length

/Meter

Energy Absorption /KJ Reaction Force /KN Energy Absorption /KJ Reaction Force /KN
0.5 1 6 64 8 85
0.7 1.5 17 137 24 180
1.0 1.5 32 182 45 239
1.0 2.0 45 257 63 338
1.2 2.0 63 297 88 390
1.5 3.0 153 579 214 761
1.7 3.0 191 639 267 840
2.0 3.5 308 875 430 1150
2.5 4.0 663 1381 925 1815
2.5 5.5 943 2019 1317 2653
3.0 5.0 1050 2000 1571 2709
3.0 6.0 1312 2488 1888 3292
3.3 4.5 1175 1884 1640 2476
3.3 6.0 1675 2783 2338 3652
3.3 6.5 1814 3015 2532 3961







RS Certified Inflatable Dock Fenders 0



RS Certified Inflatable Dock Fenders 1





Application:



It is an ideal protection tool for piers,as well as protection between ships.
It uses compressed air as a buffer medium to absorb the impact energy of the ship. Therefore,
compared with the general compression rubber protective wall, it has large energy absorption,
small reaction force, large contact area with the ship, and small unit surface pressure acting on the ship.
When tilted and compressed, the performance is not reduced, and the advantages of installation and replacement.
It can be adapted to the docking of ships in all directions.

1. Offshore platform
2. Oil and gas tankers
3. Fast ferries and aluminium vessels
4. In ports with extreme tidal variations
5. Fishing vessel, transport ship and ocean trawler



RS Certified Inflatable Dock Fenders 2



Our Certificates



RS Certified Inflatable Dock Fenders 3











FAQ:



Q1: What's your MOQ?

Answer: The MOQ of our marine rubber fender is 1pc.



Q2: What's the lifespan of your marine rubber fenders?

Answer: Designed lifespan of our marine rubber fenders is 6 to 10 years



Q3: What's your warranty period?

Answer: Our warranty period is 2 years. we will responsible for the repairment or replace the new ones for you if it proved to be our quality problem.



Q4: Can you recommend the suitable marine rubber fenders for me?

Answer:  Pls tell us your ship information, as experienced manufacturer, we will recommend suitable size and quantity for you.



Q5: What kind certificate you can provide.

Answer: CCS,BV,SGS etc.certificate is available
