Product Details:
Place of Origin: China
Brand Name: Shunhang
Certification: BV, ISO9001
Model Number: SH-MRA 8
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Price: USD2000/PC
Packaging Details: Pallet, Nylon bag
Delivery Time: 20 workdays
Payment Terms: T/T-30% in advance, 70% before delivery
Supply Ability: 200PCS/Month

Shipyard Marine Rubber Airbag Vessel Boat Docking Ship Launching Airbag

Product Name: Shipyard Using Boat Docking Marine Rubber Airbag Size: According To The Requirement
Material: Natural Rubber ; Nylon Rubber Usage: Ship Launching / Docking /Lifting / Salvage Etc.
Lifespan: 6 To 10 Years Warranty Period: 2 Years
Inflate Accessories: Included Repair Accessories: Included
High Light:

Shipyard Marine Rubber Airbag


20m vessel Marine Rubber Airbag


20m Boat Docking ship launching airbag

Shipyard Using Boat Docking Marine Rubber Airbag



Product Introduction:


Marine rubber airbags are widely used in launching and landing ship/ boat/vessel, lifting and moving heavy goods, salvaging stranded boats.


Another important feature of marine rubber airbag is that it is not only used in ships but also in other marine areas like naval salvsge, launching of caissons (large watertight chambers used for underwater construction purposes) and floating docks. The technology of marine airbags is such that if it is developed further, it can be used in many other important and necessary marine areas.


Feature of Shunhang Products:

1. Big carrying capacity

The carrying capacity of the inflating marine rubber airbag is an important indicator of its quality. The CB/T 37951996, The Airbag For The Ships Up To Slipway And Launching, specifies its working pressure and the load-bearing capacities per meter under various compression ratio. Our new generation of airbags are made of novel rubber compounding and high-tension fortifying fiber. Their carrying capacities have been over one times stronger than the standard requirements. That means that less airbags are needed for the ships up to the slipway and launching if with Shun hang marine rubber airbags meanwhile the safe reliability is also guaranteed.

2. High capacity against compression and twisting

When the airbag moves under the ship bottom, it will be compressed between the ship bottom and the ground. As the rolling velocities are not the same among them, they would be torsional deformed. This composite deformation created by both the compression and twisting is described as compressed and twisted movement. When such compression and twisting happens on the air bag, its partial wall would buckle. Then the wall in structure of the multi-layer fortifying fibers would very easily laminate and tear out, resulting the breaking of the fortifying fiber and consequentially the bursting of the entire airbag.

3. New design of anti-bursting construction at the end

For our new generation of airbags, both the rubber compounding and making process are improved so that their structural tearing strengths are improved and so for their capacity for twisting and compression resistance. The deflating possibility would increase at the joint of the end ironwork and the rubber as the working pressure rises.Once it leaks at the end after repeated operation, the end would be more likely to burst out under the high pressure and injure the people.Such accidents due to poor air bag quality have happened many times in the ship launching. We should keep alert on it. To meet the requirement on the air tightness under high internal pressure, the new anti-blasting construction is designed with the end to enhance the binding strength and air tightness at the joint of the bag body and end ironwork. This design could meet the increased working pressure and has been free of the leakage so far in use and proved safe.


Shipyard Marine Rubber Airbag Vessel Boat Docking Ship Launching Airbag 0



Some common sizes of our marine airbags, customized sizes are also available
Diameter(m) Effective Length(m) Layer Pressure(MPa)
1.0 10 5~6 0.07~0.10
1.0 12 5~6 0.07~0.10
1.0 15 5~6 0.07~0.10
1.2 10 5~6 0.08~0.12
1.2 12 5~6 0.08~0.12
1.2 15 5~6 0.08~0.12
1.5 12 5~8 0.08~0.16
1.5 15 5~8 0.08~0.16
1.5 18 5~8 0.08~0.16
1.5 20 4~8 0.08~0.16
1.5 24 5~8 0.08~0.16
1.8 12 5~8 0.08~0.15
1.8 15 5~8 0.08~0.15
1.8 18 5~8 0.08~0.15
1.8 20 5~8 0.08~0.15
1.8 24 5~8 0.08~0.15
2.0 18 6~10 0.08~0.18
2.0 20 6~10 0.08~0.18
2.0 24 6~10 0.08~0.18
2.5 18 7~10 0.07~0.13
2.5 20 7~10 0.07~0.13
2.5 24 7~10 0.07~0.13


Instruction of Marine Rubber Airbags Application In Ship Docking


1. Fasten the hull with the steel cable of traction winch.

2. Fill in one or several airbags in the optimum position of the prow bottom. After inflating, the prow shall be lifted to certain height so that the ship can be moved forward by the traction of winch. For ships with flat bottom such as barge and so on, the contacting are between airbags and the bottom is large, if the ship is light, the prow can be lifted by one airbag filled in from the prow. For ships which are difficult to feed in the airbags such as pontoon and so on, the airbags can be threaded from one side to another. If the ship is too heavy, add 1 to 2 or more airbags at certain interval until the prow can be lifted. As to power-driven ship with “V” shaped prow, the airbags must be moved to backward as the lift if not enough due to the small contacting area between the airbags and bottom of ship. Sometimes, the airbags must to be moved backward 1/4 of the length of ship to lift the prow. During being moved backward, precaution shall be taken to prevent scratching on the airbags by the stem. A “V” shaped groove can be dug firstly if possible so as to increase the contacting area between the airbags and the bottom. The coastal shipyard can bury the airbag in proper location during the low tide and pull the ship to where the airbags locate. Inflate the airbags and the ship will be lifted easily. Anyway, the shipyard may adopt applicable methods based on its own conditions.

3. Start the winch to move the ship. Feed the airbags gradually in accordance with the requirement of arrangement space until the ship is pulled to the slipway.

4. Lift ship with the help of crane, construct hard block, pad ship and remove the airbags.


Shipyard Marine Rubber Airbag Vessel Boat Docking Ship Launching Airbag 1Shipyard Marine Rubber Airbag Vessel Boat Docking Ship Launching Airbag 2

Shipyard Marine Rubber Airbag Vessel Boat Docking Ship Launching Airbag 3Shipyard Marine Rubber Airbag Vessel Boat Docking Ship Launching Airbag 4



Q1: The length you marked is effective or total length ?

Answer: All the size we marked is effective length, not include the cone head parts.


Q2: What's your MOQ?

Answer: Our MOQ is 1pc.


Q3: How about the lifespan of your marine rubber airbags?

Answer: Designed lifespan of our marine rubber airbags is  6 to 10 years


Q4: What's your warranty period?

Answer: Our warranty period is 24 monthes. we will responsible for the repairment or replace the new ones for you if it proved to be our quality problem.


Q5: What kind certificate you can provide.

Answer: CCS,SGS etc.certificate is available


Q6: I have ships but don't know how to choose the marine rubber airbags size and quantity, can you help ?

Answer: Don't worry. We have more than 20 years' experience. Pls tell us your ship information, we can suggest suitable size and quantity for you.


Q7: I want to try your marine rubber airbags, but I never use it and don't know how to use, can you help ?

Answer: Yes, we will send instruction book together with the marine rubber airbags.
